Wenglor ZVZG101 High-Resolution Lens for Smart Camera and Machine Vision Camera

High-Resolution Lens for Smart Camera and Machine Vision Camera.

$634.00
Part Number
  • ZVZG101
Highlights...

Features

  • Fixed focal length lens with C mount threaded connection
  • For image chips with small pixel sizes
  • Adjustable aperture and focus
  • Resistant to vibrations and shock
  • Focal distance: 8 mm
  • Maximum sensor size: 1/1,7
  • Minimum pixel size: 2.4 µm
  • Wavelength spectrum: Visible light
  • Lens thread: C-Mount
  • Housing Material: Aluminum, anodised, Plastic, PET, Plastic, PS
  • Optic Cover: Glass
  • Aperture: arrestable, adjustable
  • Setting range aperture: F 2,4 to 16
  • Minimum object distance: 100 mm
  • Filter Screw Size: M30.5 × 0.5 mm
  • Temperature Range: -4°F to 140°F
  • Weight: 75 g
  • Packaging unit: 1 Piece
  • Working Distance: 200 mm, 400 mm, 600 mm
  • Visual Field: 120 x 90 mm, 245 x 184 mm, 370 x 277 mm
  • Complementary Products: Allen Key with Threaded Pins Z0070, Filter, ZBVG protective tube
High-resolution, fixed focal length lenses with C mount threaded connection can be used, for example, on Machine Vision Cameras with C mount connection. They're especially well-suited for image chips with minimal pixel sizes. Adjustable aperature values and adjustable focus offer the greatest possible variability for perfect image recordings.
