Wenglor ZAV80R900 Connection Cable M12 × 1; 8-pin

Connection Cable M12 × 1; 8-pin.

$64.10
Part Number
  • ZAV80R900
Highlights...

Features

  • Screened
  • Halogen free, drag chain suitability
  • Connection 1: Socket, straight
  • Connection mode 1: M12 × 1, 8-pin
  • Connection 2: Plug, straight
  • Connection mode 2: Crimp contact, 7-pin
  • Torque: M12: 0,6 Nm
  • Coding: A-coding
  • Cable length (L): 500 mm
  • Outer diameter (d): 6 mm
  • Wire cross-section: 0.25 mm²
  • Cable Jacket Material: Plastic, PUR
  • Material Wire Insulation: Plastic, PP
  • Material Sleeve Nut: Brass, nickel-plated
  • Equipment: Shielded
  • Halogen-free: yes
  • Drag Chain Suitable: yes
  • Weight: 40 g
  • Scope of delivery: 1 × line
  • Packaging unit: 1 Piece
