Wenglor Z08M002 Mounting Console with Fixed Limit Stop for M8 × 1; Semi-Flush Mounting

Mounting Console with Fixed Limit Stop for M8 × 1; Semi-Flush Mounting.

$15.80
Part Number
  • Z08M002
Highlights...

Features

  • Integrated, fixed limit stop for precise sensor positioning
  • Time savings thanks to easy installation
  • No reduction of the switching distance
  • For M8 × 1, semi-flush
  • Material: Stainless steel, V2A (1.4305/303) / Plastic, PBT
  • Mounting: semi-flush
  • Threaded sleeve tightening torque: max. 2 Nm
  • Clamp retainer tightening torque: 0,3 Nm
  • Weight: 24 g
  • Scope of delivery: 1 × mounting console
  • Packaging unit: 1 Piece
  • Use: for threaded housing
