Wenglor SEAL01 Emergency Stop Switch Actuator

Emergency Stop Switch Actuator.

$94.60
Part Number
  • SEAL01
Highlights...

Features

  • Unlocking by turning left or right
  • 360° visible switch position indicator
  • Bright LED illumination in blocking protection flanges
  • Temperature Range: -22°F to 131°F
  • Storage temperature: -58°F to 185°F
  • Housing Material: Plastic
  • Service Life (Activations): 50000
  • Degree of Protection: IP65
  • Installation Type: Mounting
  • Installation opening: 22.3 mm
  • Unlocking: turning
  • Connection Type: XXX
  • Connection: Screw-type connection
  • Weight: 52 g
  • Packaging unit: 1 Piece
  • Scope of delivery: 1 × actuator
  • Switching position indicator: yes
  • Anti-Lock Collar: yes
  • Illumination: yes
  • Complementary Products: Installation Tool Z0046, Software
