Wenglor OPT175-P08 Retro-Reflex Sensor for Roller Conveyor Systems

Features

• Fully encapsulated
• Integrated logic
• Recognition of high-gloss and jet black objects
• Large working range
• Range: 6,500 mm
• Reference Reflector/Reflector Foil: RQ100BA
• Min. Distance to Reflector: 100 mm
• Switching Hysteresis: < 15 %
• Light Source: LED, red
• Polarization Filter: yes
• Service Life (T = 77°F): 100,000 h
• Max. Ambient Light: 10,000 Lux
• Opening Angle: 5 °
• Optics: Two-Lens Optic
• Supply Voltage: 18 to 30 V DC
• Current Consumption Sensor (Ub = 24 V): < 25 mA
• Switching Frequency: 100 Hz
• Response Time: 5 ms
• Temperature Drift: < 10 %
• Temperature Range: 5°F to 122°F
• Number of Switching Outputs: 1
• Switching Output Voltage Drop: < 0.8 V
• PNP Switching Output/Switching Current: 200 mA
• Short Circuit Protection: yes
• Reverse Polarity Protection: yes
• Overload Protection: yes
• Single Discharge: yes
• Block Forwarding: yes
• Protection Class: III
• Housing Material: Plastic, PBT
• Full Encapsulation: yes
• Degree of Protection: IP65
• Connection Type: 1 socket with cable
• Connection: M12 × 1; 4-pin
• Cable length (L): 2 m
• Cable Jacket Material: PVC
• Weight: 276 g
• Scope of delivery: 1 × molded seal, 1 × initial start-up instructions, 1 × VENTIL-K03 solenoid valve, 1 × M2.5 screw × 22 mm
• Valve no.: K03
• Supply Voltage Valve: 21.6 to 26.4 V
• Current Consumption Valve: 42 mA
• Operating Pressure: 0 to 8 bar
• Nominal Width: 0.9 mm
• Nominal flow rate 1 -> 2: 22 NL/min
• Nominal flow rate 2 -> 3: 25 NL/min
• Supply-Line Connector Pipe: 2× 8×1
• Working-Line Connector Pipe: 4×1
• Valve function: 3/2-Way
• Switching function: NO
• PNP NO: yes
• ZRAE02B01: 0.2 to 1.8 m
• ZRME03B01: 0.15 to 2 m
• ZRDF03K01: 0.1 to 3.5 m
• ZRDF10K01: 0.1 to 4.5 m
• Complementary Products: Adapter OPT70N, OPT70S, OPT70P, Reflector, Reflector Foil
