Wenglor OPT1600 Retro-Reflex Sensor

Retro-Reflex Sensor.

$693.00
Part Number
  • OPT1600
Highlights...

Features

  • Large working range
  • Fully encapsulated
  • Recognition of high-gloss and jet black objects
  • Integrated logic
  • Range: 6,500 mm
  • Reference Reflector/Reflector Foil: RQ100BA
  • Min. Distance to Reflector: 100 mm
  • Switching Hysteresis: 15 %
  • Light Source: LED, red
  • Polarization Filter: yes
  • Service Life (T = 77°F): 100,000 h
  • Max. Ambient Light: 10,000 Lux
  • Opening Angle: 5 °
  • Optics: Two-Lens Optic
  • Supply Voltage: 18 to 30 V DC
  • Current Consumption Sensor (Ub = 24 V): < 30 mA
  • Switching Frequency: 100 Hz
  • Response Time: 5 ms
  • Temperature Drift: < 10 %
  • Temperature Range: 5°F to 122°F
  • Number of Switching Outputs: 1
  • Switching Output Voltage Drop: < 0.8 V
  • PNP Switching Output/Switching Current: 200 mA
  • Short Circuit Protection: yes
  • Reverse Polarity Protection: yes
  • Overload Protection: yes
  • Single Discharge: yes
  • Block Forwarding: yes
  • Protection Class: III
  • Setting Method: Potentiometer
  • Housing Material: Plastic
  • Full Encapsulation: yes
  • Degree of Protection: IP65
  • Connection Type: 1 socket with cable
  • Connection: M12 × 1; 4-pin
  • Cable length (L): 2 m
  • Weight: 282 g
  • Scope of delivery: 1 × Z0034 molded seal, 1 × initial start-up instructions, 1 × VENTIL-K04 solenoid valve, 1 × M2.5 screw × 22 mm, 1 × sensor
  • Valve no.: K04
  • Supply Voltage Valve: 19.2 to 28.8 V
  • Current Consumption Valve: 86 mA
  • Operating Pressure: 4 to 7 bar
  • Nominal Width: 0.8 mm
  • Nominal flow rate 1 -> 2: 20 NL/min
  • Nominal flow rate 2 -> 3: 100 NL/min
  • Supply-Line Connector Pipe: 2× 8×1
  • Working-Line Connector Pipe: 4×1
  • Valve function: 3/2-Way
  • Switching function: NC
  • PNP NO: yes
  • RQ100BA: 0.25 to 6.5 m
  • RE18040BA: 0.1 to 4 m
  • RQ84BA: 0.25 to 5 m
  • RR84BA: 0.2 to 5 m
  • RE9538BA: 0.15 to 2 m
  • RR50_A: 0.15 to 3 m
  • RE6040BR: 0.2 to 2.5 m
  • RE8222BA: 0.25 to 1.8 m
  • ZRAE02B01: 0.2 to 1.8 m
  • ZRME03B01: 0.15 to 2 m
  • RF505: 0.15 to 1.9 m
  • RF508: 0.15 to 1.9 m
  • RF258: 0.15 to 1.5 m
  • ZRDF03K01: 0.1 to 3.5 m
  • ZRDF10K01: 0.1 to 4.5 m
  • Complementary Products: Reflector, Reflector Foil, Adapter OPT70N, OPT70S, OPT70P
These sensors have been specially designed for use in accumulation roller conveyors. Their compact design allows for installation between two rollers below the conveyor level. They are thus protected against mechanical damage.
