Piab Suction cup OF15x45P Polyurethane PU50, G1/8" male

This program of oval suction cups has characteristics that are specially suited for handling of metal-sheet material.

$38.77
Part Number
  • OF15X45P.5D.G31M
Highlights...

Features

  • Suitable for flat and rough surfaces.
  • Fair stability and little inherent movement.
  • Recommended when the lifting force is parallel to the surface of the object.
  • Cleats prevent thin, sensitive objects from being deformed and give extra friction when the lifting force is parallel to the surface of the object.
  • DURAFLEX® are suction cups manufactured in a specially developed material that features the elasticity of rubber and wear resistance of polyurethane. The material does not leave any marks on the objects handled.
  • Swivel option, prior to the locking operation, for easy positioning of the oval cup.
  • Material: Polyurethane (PU)
  • Dimensions: 1.77 in. (depth) x 0.59 in. (width) x 0.68 in. (length), 0.02 lb. (weight)
  • Fitting Size: 18 mm.
