Advantech FPM-8151H-R3BE

15" XGA Industrial Monitor for Hazardous Location, with 316L Stainless Steel Front Panel, C1D2 certified.

$1,898.00
Part Number
  • FPM-8151H-R3BE
Highlights...

Features

  • Ingress Protection: Front Panel IP65
  • Relative Humidity: 95% RH (non-condensing)
  • Vibration Protection: 1 Grms, random
  • Humidity (Operating): 10~95% RH (non-condensing)
  • Humidity (Storage): 10~95% RH (non-condensing)
  • Rated Voltage: 24 VDC
  • Certification: CB, UL, CE, FCC Class A, CCC, BSMI, C1D2
  • I/O: 1 x VGA, 1 x DVI, 1 x RS-232, 1 x USB
  • OS Support: Windows 2000, XP, Vista, 7, XPe, CE and Linux
  • OSD Controls: OSD panel on front panel
  • Power Consumption: 12 W @ 24 VDC
  • Power Input: 24 VDC
  • Power Requirement: 24 VDC
  • Video Port: VGA, DVI
  • Power Connector: 1 x 3-Pin Terminal Block
  • Display Size: 15"
  • Max. Resolution: 1024 x 768
  • Viewing Angle (H/V°): 160/140
  • Dimension (W x H x D): 422 x 338 x 68 mm
  • Enclosure: 316L Stainless Steel
  • Form Factor: Passive Cooling
  • Mounting: Panel
  • Weight (Net): 8.5 kg (18.74 lb)
  • Touch Type: 5-wire resistive
  • 15" XGA TFT LCD with "LED backlight"
  • Stainless steel 316L front panel
  • IP65 compliant front panel
  • Enhanced 5-wire resistive touch panel
  • Direct VGA & DVI-D video input interface
  • Combo RS-232 & USB interface for touchscreen function
  • Supports 24 VDC input and 100~240 VAC input (optional AC adapter)
  • OSD control pad with lockable function on front panel
  • Certified with UL CID2 for hazardous environment
The FPM-8151H is a particularly rugged and reliable 15” XGA wide temperature industrial monitor for a variety of industry applications. Equipped with a wide operating temperature range of -20 ~ 60°C (-4 ~ 140°F), it can satisfy demands in a wide range of harsh industrial applications. This model also features enhanced 5-wire resistive touch and system isolation to enhance the reliability. Moreover, FPM-8151H is designed to be safely operated in these locations and is certified with UL Class I Division 2 for hazardous environment.
