Name: Advantech EKI-1526I-CE
Price: 1381.0 USD
Availability: BackOrder

Advantech EKI-1526I-CE — Advantech-EKI-1526I-CE

Advantech-EKI-1526I-CE
Advantech-EKI-1526I-CE
Advantech-EKI-1526I-CE
Advantech-EKI-1526I-CE

$1,381.00

Part Number

EKI-1526I-CE

Highlights...

EKI-1526I-CE
By Advantech
FREE Shipping
Call for availability

Features

EMC: CE, FCC
EMI: EN 55011/ EN 55032 Class A, EN 61000-6-4, FCC Part 15 Subpart B Class A
EMS: EN 61000-4-2 (Level 4), EN 61000-4-3 (Level 3), EN 61000-4-4 (Level 4), EN 61000-4-5 (Level 4), EN 61000-4-6 (Level 3), EN 61000-4-8 (Level 4), EN55024
Freefall: IEC 60068-2-32
Safety: UL 60950-1, UL 62368
Vibration: IEC 60068-2-6
RJ-45 Port Connector Type: RJ-45
Serial Port Connector Type: DB9
Temperature (Max. Operating): 70Â°C (158Â°F)
Ethernet Standard: IEEE 802.3, 802.3u, 802.3ab
IP Rating: IP30
Weight: 3.1 kg
Power Consumption: 5.6W
Power Input (AC): 100 ~ 240 VAC
Power Operating Current: 0.3A @ 110 VAC ;
0.2A @ 220 VAC
Reverse Polarity: Present
RS-232: Yes
RS-422: Yes
RS-485: Yes
Baud Rate: 50 ~ 921.6 Kbps
Serial Transmission Speed: 50 ~ 921.6 Kbps
Configuration: Windows utility, Telnet console, Web Browser
Driver: Windows XP/7/8.1/10, Windows Server 2003/2008/2012/2016/2019, and Linux
Operation Mode: Virtual COM, TCP/UDP server TCP/UDP client
Warranty Period: 5 years
Provides 2 x 10/100/1000 Mbps Ethernet ports for LAN redundancy
Supports up to 976.5 kbps, and any baud rate setting
Provides COM port redirection (Virtual COM), TCP and UDP operation modes
Provides rich configuration methods: Windows utility, Telnet console, Web Browser, and serial console
Built-in 15 KV ESD protection for all serial signals
SNMP MIB-II for network management
Built-in buzzer for easy location
Standard 1U rackmount size
Automatic RS-485 data flow control
"I" models support a wide operating temperature

The EKI-1528 and EKI-1526 are industrial-grade network-based serial device servers for connecting up to 8 or 16 serial RS-232/422/485 devices, such as CNCs, PLCs, scales and scanners, directly to a TCP/IP network. The EKI-1528 and EKI-1526 feature two independent Ethernet ports and MAC addresses to provide a redundant network mechanism to guarantee Ethernet network reliability. The EKI-1528 and EKI-1526 provide a simple and cost-effective way to bring the advantages of remote management and data accessibility to thousand of devices that can't connect to an Ethernet network. The EKI-1528 and EKI-1526 offer multiple ways to configure through Windows utility, Web Browser, serial console or Telnet console, these methods make it easy manage many EKI-1528 and EKI-1526 or serial devices on your network.
