Aventics PSG1 Series Piezoelectic Controller

Frequency converter for use with the HLF-P Series Linear Feeder. Adjustable drive frequency, constant delivery rate, and external control via enable input.

Call for pricing

Please fill out this Feeding Solutions Application Form. A Motion World engineer will be in touch to advise on the configuration your system requires.

Part Number
  • PSG1 Series
Highlights...

Features

  • Only suitable for operating HLF-P linear feeders
  • Adjustable drive frequency
    • Mains frequency-independent
  • Allows constant conveyor capacity

The Aventics PSG1 Series Piezoelectic Controller is a frequency converter for operating vibratory conveyor technology which incorporates a piezo drive, namely the HLF-P linear feeders. The PSG1 generates an adjustable drive frequency that is independent of the mains. The output voltage is adapted to the piezo drive within a generated range of -30 to 150V. The PSG1 Series ensures a constant delivery rate in the event of mains voltage fluctuations, and can be controlled externally via an enable input without triggering upstream capacitors.
