Aventics CL03-EV 5/2SR-024DC/NI/IP69K Electric and Pneumatic Actuated Directional Valve

Single valve, Spool valve, suitable for use in food processing. View other configurations.

Aventics CL03-EV 5/2SR-024DC/NI/IP69K Electric and Pneumatic Actuated Directional Valve — Aventics-CL03-EV 5/2SR-024DC/NI/IP69K

$262.31

Part Numbers

CL03-EV 5/2SR-024DC/NI/IP69K
R412017962

Highlights...

CL03-EV 5/2SR-024DC/NI/IP69K
By Aventics
FREE Shipping on orders of $1,000 or more
Usually ships in 5 weeks

Features

Activation: Electrically
Certifications: UR (Underwriters Laboratories)
Compressed air connection output: Ø 8
Flow L M: 700 l/min
Housing Material: Polyamide fiber-glass reinforced
Industry: Industrial
Manual Override: with detent
Max Working Pressure: 10 bar
Min Working Pressure: -0.9 bar
Operating Voltage: 24 V DC
Seat Seal Type: Soft seal
Switching principle: 2/2, with spring/air spring return
Valve Pilot: External
Voltage tolerance: -15% / +20%
Wattage: 0.35 W
Dimension: 9.45x7.48x5.51 (inches)

View other configurations.

AVENTICS 5/2-directional valve, Series CL03-EV R412017962
