Piab Vacuum Check Valve VT1 COAX® cartridge MINI Pi12-2, non-return valve G3/8"-G1/4"

Name: Piab Vacuum Check Valve VT1 COAX® cartridge MINI Pi12-2, non-return valve G3/8"-G1/4"
Price: 286.1 USD
Availability: BackOrder

Choose between solenoid, electrically or vacuum-controlled valves. The vacuum controlled valve (Vacustat) shuts off the flow of compressed air to the pump when the pre-set level is reached, and consequently the consumption of compressed air is minimised.

$286.10

Part Number

Highlights...

Check valve that traps vacuum in sealed applications for safe operation.
Built-in blow off check valve for fast release of object.
Optional two-stage COAX® cartridge MINI Pi12-2 integrated.
Optional integrated energy-saving device, Vacustat results in virtually no air consumption in sealed applications.
Recommend using 4mm (5/32”) tubing and no more than 80 psi for blow off.
Recommend using 6mm (1/4”) tubing and no more than 80 psi for vacuum.
Equal line lengths from common manifold should be used for both blow-off and vacuum.
Maximum of (12) units per tool.
Material: Nitrile (NBR);Al;CuZn;PA;PP;SS;Steel;Ceramic
Temperature: 14 °F
Dimensions: 0.86 lb. (weight)
Feed Pressure (Max): 0.55 MPa
