Piab COAX® cartridge MINI Pi12-2, extra non-return valve

COAX® is an advanced solution for creating vacuum with compressed air. Based on Piab’s multistage technology, COAX® cartridges are smaller, more efficient and more reliable than conventional ejectors, that allows for the design of a flexible, modular and .

$57.10
Part Number
  • 01.06.963
Highlights...

Features

  • Two-stage COAX® cartridge - MINI - with small mounting dimensions.
  • Vacuum level to 27 -inHg at low feed pressures.
  • High operational reliability in case of fluctuating or low compressed-air pressure.
  • Suitable for handling sealed objects.
  • Used in PMAT, VGS™3010 and VGS™3040.
  • Material: Nitrile (NBR);Al;PA;SS
  • Temperature: 14 °F
  • Dimensions: 0.01 lb. (weight)
  • Feed Pressure (Max): 0.7 MPa
