Aventics SA Series Telescope Spindle Axis

Compact, high precision spindle axis with variable diameters available to meet various positioning and high automation needs.

Call for pricing
Part Numbers
  • SA Series
  • SA-1
  • SA-3
  • SA-6
Highlights...

Features

  • Measuring system: resolver
  • Spindle diameter:
    • SA-1: 8mm
    • SA-3: 10mm
    • SA-6: 12mm, 12.7mm
  • Drive shaft diameter:
    • SA-1: 4mm, 12mm
    • SA-3: 6mm
    • SA-6: 8mm
  • Operating temperature: 10 to 40°C
  • Humidity: < 90 %
  • IP30 protections
  • Stroke H:
    • SA-1/-3: 50 to 150mm
    • SA-6: 100 to 300mm
  • Drive: AC Servo
  • Max speed:
    • SA-1: 0.3m/s
    • SA-3: 0.5m/s
    • SA-6: 0.6m/s
  • Peak force:
    • SA-1: 150N
    • SA-3: 300N
    • SA-6: 600N
  • Repeat accuracy: 0.01mm
  • Extremely compact
    • Higher power density for -FL variant
  • Flexible motor mounting
  • Precise spindle drive

The Aventics SA Series Telescope Spindle Axis is a durable, precise spindle axis that offers easy integration into automation systems. Spindle diameters from 8 to 12.7mm, with drive shafter diameters from 4 to 8mm offer adaptability to application requirements, with a highly compact design and higher power density to optimize space and productivity. All models offer within 0.01mm repeat accuracy, providing a high precision solution for various industrial tasks involving positioning and rapid actuation.
