Advantech MIC-1816-U0A1E

Features

• Input Range: ±0.625 V, ±1.25 V, ±2.5 V, ±5 V, ±10 V, 0~1.25 V, 0~2.5 V, 0~5 V, 0~10 V
• Resolution(Bits): 16-bit
• Sampling Rates(S/s): 1 MS/s (sum)
• Output Ranges: 0~5 V, 0~10 V, ±5 V, ±10 V
• Resolution: 16-bit
• Update Rate(S/s): 3 MS/s
• Counting Range: 32-bit
• Max. Input Frequency: 10 MHz
• Channels: 16 (Isolated)
• Channels: 8 (Isolated)
• Programming Language: C#, C++, LabVIEW, VB.Net, BCB, MFC, VB6, Delphi, Java, Matlab, Qt
• Certification: CB, UL, CE, FCC Class A, CCC, BSMI
• Input Voltage: 10~30 VDC
• 16x analog inputs, up to 1 MS/s, 16-bit resolution
• 2x analog outputs, up to 3 MS/s, 16-bit resolution
• Support for digital trigger and analog trigger
• 16x isolated digital input and 8 x isolated digital output
• 2x 32-bit programmable counter/timers
• Onboard FIFO memory (4,096 samples)
• 2 x RS-232/422/485 ports
• 2 x 10/100/1000 Base-T RJ-45 LAN ports
• 2 x USB 2.0 and 2 x USB 3.0 ports
• iDoor expansion supported
