Aventics IRG1-D Series Phase Angle Controller
Controller module for stepless control of bowl feeders and linear feeders. Full and half-wave operation, with external control by PLC available.
Please fill out this Feeding Solutions Application Form. A Motion World engineer will be in touch to advise on the configuration your system requires.
- IRG1-D Series
- IRG1-D Series
- By Aventics
- FREE Shipping on orders of $1,000 or more
Overview
Features
- 100% downward compatible with previous generations
- Available with swing amplitude control
- User data storage
- Soft start and stop
- Full and half-wave operating modes
Description
The Aventics IRG1-D Series Phase Angle Controller is utilized for stepless control of inductive loads, including bowl feeders and linear feeders. This series permits operation of vibratory feeders with a vibration frequency up to 120Hz, with full or half-wave operation available. Smooth, jerk-free starts and stops can be triggered from the mains switch or the control input. Activating or deactivating the unit can also occur via PLC through an enable input (24 VDC signal or potential-free contact). The IRG1-D Series controller modules offer consistent, precise control over various feeding applications, and easy integration into existing systems.
