Festo 539709 / MSSD-C-M16 Plug Socket

$5.56
Part Numbers
  • MSSD-C-M16
  • 539709
Highlights...

Features

  • 50 frequency of connection
  • On solenoid valve via M3 central screw type of mounting
  • Optional mounting position
  • 38G product weight
  • 3-pin electrical connection
  • Angled socket electrical connection
  • Type A electrical connection
  • To DIN EN 175301-803 electrical connection
  • Square design electrical connection
  • M16 cable fitting
  • 1.5I2 connection cross section
  • IP65 degree of protection
  • To IEC 60529 degree of protection
  • VDMA24364-B2-L lABS (PWIS) conformity
  • RoHS-compliant note on materials
  • PA-reinforced material housing
  • HNBR material seals
  • -20GC ambient temperature to 115GC ambient temperature
  • 6MM to 8MM permissible cable diameter
