Festo CPV14-M1H-VI95-2GLS-1/8 Vacuum Generator

$349.32
Part Numbers
  • CPV14-M1H-VI95-2GLS-1/8
  • 185871
Highlights...

Features

  • 0.95MM nominal size, laval nozzle
  • Optional mounting position
  • High vacuum ejector characteristic
  • 991561 symbol
  • 85% max. vacuum
  • Compressed air to ISO 8573-1:2010 [7:4:4] operating medium
  • Lubricated operation possible (in which case lubricated operation will always be required) note on operating and pilot medium
  • 1 - Low corrosion stress corrosion resistance class cRC
  • VDMA24364-B1/B2-L lABS (PWIS) conformity
  • 0GC media temperature
  • 50GC media temperature
  • 114G product weight
  • Plugs electrical connection
  • With through-hole type of mounting
  • G1/8 vacuum connection
  • RoHS-compliant note on materials
  • Die-cast aluminium material housing
  • 2BAR to 10BAR operating pressure
  • 0GC ambient temperature to 50GC ambient temperature
  • Pneumatic connection sub-base , port 1
  • Pneumatic connection sub-base , port 3
